Mini tracked skid steer loader is Multi-functional construction equipment, it is small and easy to control.it could be easily and quickly attached to various accessories to achieve various works. our skid steer loader is widely used in gardens, manufacturing, construction sites, recycling, gardens, roads, Construction, farms and other industrial fields...
Item | HJ648T ( Tracked type ) |
Machine weight | 1330kgs |
Bucket capacity | 400kg-500kg |
Bucket volume | 0.2CBM |
Total length（L）（with bucket） | 2700mm |
Total length（L）（without bucket） | 2070 mm |
Total width （W） | 1060mm |
Wheelbase （G） | 760mm |
Total height （H） | 1500mm |
Operating height | 2580mm |
Height to bucket pin | 1900 mm |
The height from the ground | 160mm |
Dump height | 1800mm |
Angle of departure | 23° |
Tire size | 12.3x8.50-12 |
Diesel Engine | Kubota/Perkins 403D diesel |
Engine power | 18.4kw (25hp) |
Number of cylinder | 3 |
speed | 2600RPM |
Displacement | 1.496L |
Working system pressure | 180 bar |
Electric voltage | 12V |
Working system flow rate | 40L/m |
Diesel oil tank | 40L |
Hydraulic oil tank | 36L |
Driving system pressure | 250 bar |
Driving system flow rate | 65L/m |
Driving speed | 0-8km/h |
